Tube O.D inch

NPT thread

Part Number

C

L

P

R

W inch

Min bore

inch

mm

inch

mm

inch

mm

inch

mm

mm

inch

mm

1/16

1/16

1MET1N

0.58

14.7

0.44

11.2

0.56

14.2

0.38

9.7

9.7

3/8

0.05

1.3

1/8

1/8

2MET2N

0.78

19.8

0.53

13.5

0.52

13.2

0.38

9.7

9.7

7/16

0.09

2.3

3/16

1/8

3MET2N

0.81

20.6

0.56

14.2

0.58

14.7

0.38

9.7

9.7

7/16

0.13

3.3

1/4

1/8

4MET2N

0.93

23.6

0.63

16.0

0.66

16.8

0.38

9.7

9.7

9/16

0.19

4.8

1/4

1/4

4MET4N

0.96

24.4

0.66

16.8

0.86

21.8

0.56

14.2

14.2

9/16

0.19

4.8

5/16

1/8

5MET2N

0.95

24.1

0.66

16.8

0.66

16.8

0.38

9.7

9.7

9/16

0.19

4.8

3/8

1/4

6MET4N

1.01

25.7

0.72

18.3

0.86

21.8

0.56

14.2

14.2

9/16

0.28

7.1

1/2

3/8

8MET6N

1.13

28.7

0.75

19.1

0.95

24.1

0.56

14.2

14.2

3/4

0.41

10

5/8

1/2

10MET8N

1.19

30.2

0.81

20.6

1.17

29.7

0.75

19.1

19.1

7/8

0.50

13

3/4

3/4

12MET12N

1.22

31.0

0.84

21.3

1.20

30.5

0.75

19.1

19.1

1.1/16

0.63

16

7/8

3/4

14MET12N

1.32

33.5

0.94

23.9

1.27

32.3

0.75

19.1

19.1

1.5/16

0.72

18

1

1

1MET1N

1.66

42.2

1.19

30.2

1.48

37.6

0.94

23.9

23.9

1.5/16

0.88

22

Metric Tubing

Tube O.D mm

NPT thread

Part Number

C

L

P

R

W inch

Min bore
mm

mm

mm

mm

mm

6

1/8

6MMET1/8N

17.7

16.0

16.8

9.5

9/16

4.8

6

1/4

66MMET1/4N

17.7

16.0

21.8

14.3

9/16

4.8

8

1/8

8MMET1/8N

18.6

16.8

16.8

9.5

9/16

4.8

10

1/4

10MMET1/4N

19.5

19.0

24.1

14.3

3/4

7.1

12

3/8

12MMET3/8N

22.0

19.0

24.1

14.3

3/4

9.5

12

1/2

12MMET1/2N

22.0

20.6

29.7

19.0

7/8

9.5

16

1/2

16MMET1/2N

22.0

20.6

29.7

19.0

7/8

12.7
